Replacement rear bearing kit used on some Crosley, Frigidaire, Gibson, Kelvinator, Kenmore, Tappan, Universal / Multiflex, and White-Westinghouse dryer models.
Directly Replaces: 5303281153, 3281153, 85-852, DE724, Q000142850, Q142850, WQ142850, B005B9DP4I, 1851, AH459829, AP2142648, EA459829, EAP459829, PD00000097, PS459829, 131777700, 131168200, 131825900, 131724301, 131205400, 5303281019, 5303281020.
Features:
- Supports the dryer drum.
- Pre-tapped plate for easy installation.
- Includes 131777700 ball shaft replacement, (3) 131168200 ball shaft screw replacements, (3) washers, 131825900 Teflon shaft bearing replacement, 131724301 shaft bearing bracket replacement, (2) 131205400 shaft bracket screw replacements, 5303281019 ball bearing replacement, 5303281020 ball bearing clip replacement, and high-temperature lubricant.
Specifications:
- Material: Metal / Teflon.
- Ball Shaft Dimensions: 5-1/8"L x 2-1/4"W x 5-1/8"H.
- Additional Dimensions: Bearing measures 1-15/16"L x 1"W x 1 3/8"H with mounting holes 1-1/2" apart (center to center).
Compatible Models:
Don't see your model listed? Submit this form to get help finding the right part.
Repair Skill Level: 2 | Beginner to Moderate
Minimal disassembly (if any) and some basic tools may be needed.
Part Description: The rear bearing helps to support the dryer drum.
Failure Symptoms: Dryer making a squealing or grinding noise when rotating.
Testing: Remove the dryer belt and try turning the drum by hand. If the drum will rotate freely, and without noise, the bearing is likely not the problem. However, the drum is difficut to turn or makes a squealing or grinding noise the rear drum bearing could need replaced.
Bonus Tip: Overloading the dryer is a common cause of broken dryer parts. Learn your dryer's max capacity to get the best longevity out of it.
Disclaimer: Information and recommendations contained herein are believed to be accurate as of the date hereof. Since the conditions and methods of use of the information referred to are beyond control, ApplianceRepairForum.com and Thrifty Appliance Parts LLC, cannot be held liable for results obtained or arising from use or reliance on such information.
The User assumes responsibility associated with making test measurements, adjustments, parts replacements and any other action necessary to perform any recommended procedures. It is the responsibility of the User to ask for clarification if a recommendation is not fully understood, including the risks and hazards associated with the recommended procedures.
-
Dryer rear bearing kit
Great replacement. All components fit perfectly, although I chose to use the original attachment bolts as their thread pattern provided a better grip on the backing plate. Thanks, would certainly purchase again!
-
dryer bearing kit
Worked like a charm. Arrived in a timely fashion. No complaints.
-
Problem Solved!.
The repair parts corrected the noise problem. Simple to do, great price and fast delivery.
-
Worked perfectly...
This product was just what I needed to fix my squeaky dryer, got it in a few days, took maybe an hour (moving the dryer, cleaning, installing, etc.) And now my dryer works like new.
