Replacement ice maker kit used for some Amana, Crosley, Estate, Ikea, Inglis, Jenn Air, Kenmore, KitchenAid, Maytag, Roper, Thermador, and Whirlpool refrigerator models.
Directly Replaces: 4317943, 4317943R, 4317943VP, 4210317, 4211173, 480616, 480617, 482014, 482015, 482016, 482017, 482018, 482019, 482020, 482394, 482433, 482990, 625601, 625603, 625610, 625611, 625622, 625625, 625653, 625656, 625660, 626002, 626201, 626237, 626366, 626461, 626489, 626608, 626636, 626640, 626609, 626626, 626670, 626687, 627572, 68972-4, 797991, 8114, 833701, 978552, 978553, 978556, 99989730, 46000978556, 46004211173, ER4317943, J21791, J22241, M626687, RIM500, RIM943, TJ90RIM943, W10632400, W10122496, W10190952, W10281545, B008DJX79Q, B008DJWLFC, B008DJZ0MI, B008DJW0CQ, B00DM8JA80, B008DJKF9Q, B008DJWKYE, B008DJXCB4, B008DK3ULA, B008DK78PO, B008DJXFWK, B008DJWJN6, B008DJVOSW, B008DJWI7I, B008DJZATG, B008DJWLQG, B008DJWHT2, B008DJVP8Q, B008DJWLAM, B018A35XMS, B008DJVXGA, B008DJWIZU, B00NMNLHQ8, B0085SV2E2, B008DK2LE2, B00DUIJ4R4, B00HJXYSYA, B008DJYYC0, B005HFB75K, B00M63GZXK, B008DK7976, B008DJWK1M, B008DJXGLK, B008DK4IYS, B008DJVPVI, B008DJX5J8, B008DJVEBY, B008DJXAA2, B008DJXLBU, B008DJXEI0, B008DJIZOS, B008DJVESW, B008DJI7NC, B008DJWJBS, B008DJVPHW, B008DJWZOO, B008DJVO1E, B008DJXHFA, B008DJX7R8, B008DJXOMQ, B008DK5838, B008DJVODC, B008DK78VS, 1857, AH358591, AP2984633, EA358591, EAP358591, PD00002471, PS358591.
Features:
- Creates ice cubes to be stored in the ice bin.
- Replaces most ice makers made by Whirlpool, Kitchen Aid, Kenmore for models starting with 106. However, it does not fit models that have the ice container in the door and electronic ice level sensor.
- INCLUDES bail arm.
- Some models may require re-using the original wire harness for proper installation.
- Includes (1) 8-Cube Ice Maker Assembly with Bail Arm, (1) Round Style Plug Wire Harness, (1) Linear Style Plug Wire Harness, Installation Hardware, Instructions.
Specifications:
- Color: White / Black / Gray.
- Material: Plastic / Metal.
- Finish: Glossy.
- Electrical Specs: 115V, 60Hz, 1.6W.
- Dimensions: 11-1/4"L x 4-5/8"W x 4-3/4"H.
- Additional Dimensions: Wire harness with round style plug measures 12"L. Wire harness with linear plug measures 10 7/8"L.
- View Instructions.
Compatible Models:
Don't see your model listed? Submit this form to get help finding the right part.
Repair Skill Level: 2 | Beginner to Moderate
Minimal disassembly (if any) and some basic tools may be needed.
Part Description: The ice maker module connects to the water line to automatically create ice cubes within the refrigerator/freezer.
Failure Symptoms: Ice maker not producing any ice, or over producing ice.
Testing: Check to make sure that the ice level arm isn't in the off position, the water line isn't blocked or frozen, the water filter isn't clogged, the water inlet valve isn't defective, the thermostat isn't set too low causing it to freeze up. If none of those is causing the failure, it may be time to replace your ice maker.
Bonus Tip: If your freezer temperature is more than 10 degrees Fahrenheit, the ice maker will not work efficiently. The temperature inside the freezer compartment should be between 0 and 5 degrees Fahrenheit for proper ice maker functionality.
Disclaimer: Information and recommendations contained herein are believed to be accurate as of the date hereof. Since the conditions and methods of use of the information referred to are beyond control, ApplianceRepairForum.com and Thrifty Appliance Parts LLC, cannot be held liable for results obtained or arising from use or reliance on such information.
The User assumes responsibility associated with making test measurements, adjustments, parts replacements and any other action necessary to perform any recommended procedures. It is the responsibility of the User to ask for clarification if a recommendation is not fully understood, including the risks and hazards associated with the recommended procedures.
-
