WB24T10022 Range 6" Burner Infinite Switch For Kenmore

(No reviews yet) Write a Review
SKU: APNWB24T10022K
Condition: New
Compatible Brands:
GE
Compatible Brands:
Hotpoint
Compatible Brands:
Kenmore
$53.28
$26.75
(You save $26.53 )

5% Off Orders Over $75

© 2024 Thrifty Appliance Parts           Some photos taken on 1" x 1" grid.

Replacement infinite switch used for some GE, Hotpoint, and Kenmore range models.

Directly Replaces: WB24T10022, 164D1816P06, 769689, AH236747, AP2024071, EAP236747, PD00034471, PS236747.

Features:

  • Regulates the heat level of the burner element.
  • Typically used with 6" burner elements.
  • Includes (1) 5-Terminal Infinite Switch.

Specifications:

  • Color: Gray / Almond.
  • Material: Plastic / Metal.
  • Electrical Specs: 240V, 1250W, 4.4-5.8A.
  • Dimensions: 1-3/4"L x 2-1/8"W x 2-5/16"H.

Compatible Models:

How do I find my model number?
WB24T10022 Range 6" Burner Infinite Switch For Kenmore

Repair Skill Level: 2 | Beginner to Moderate
Minimal disassembly (if any) and some basic tools may be needed.

Part Description: Regulates the heat level of the burner element.

Failure Symptoms: Cannot control the burner temperature, or cannot turn the burner on/off; Burner will not heat.

Testing: If you're unable to control an electric burner, the burner's infinite switch should be replaced.

Bonus Tip: Easily determine if the element or switch is defective by switching the non-working element with a working one. If the new element works, the the old element was defective. If the new element does not work, it likely that the switch is defective.
