Replacement ice maker used for some Ikea, Jenn-Air, Kenmore, KitchenAid, Maytag, and Whirlpool refrigerator models.
Directly Replaces: WPW10251076, W10122576, W10251076, 1937445, AP4558158, AP6017832, EAP3494406, PD00027641, PS3494406, PS11751133.
- Creates ice cubes to be stored in the ice bin.
- Typically used in side by side refrigerators with in door ice system.
- Includes (1) 6-Cube Ice Maker Assembly with 4-Wire Harness.
- Color: White / Black / Gray.
- Material: Plastic / Metal.
- Finish: Glossy.
- Electronic Specs: 115V, 60Hz, 200W, 1.8A.
- Dimensions: 9-3/4"L x 5-7/8"W x 5-3/4"H.
- Additional Dimensions: 4-Wire harness and plug extend approx. 7" from ice maker.
Repair Skill Level: 2 | Beginner to Moderate
Minimal disassembly (if any) and some basic tools may be needed.
Part Description: The ice maker module connects to the water line to automatically create ice cubes within the refrigerator/freezer.
Failure Symptoms: Ice maker not producing any ice, or over producing ice.
Testing: Check to make sure that the ice level arm isn't in the off position, the water line isn't blocked or frozen, the water filter isn't clogged, the water inlet valve isn't defective, the thermostat isn't set too low causing it to freeze up. If none of those is causing the failure, it may be time to replace your ice maker.
Bonus Tip: If your freezer temperature is more than 10 degrees Fahrenheit, the ice maker will not work efficiently. The temperature inside the freezer compartment should be between 0 and 5 degrees Fahrenheit for proper ice maker functionality.
