3392519 Dryer Thermal Fuse For Kenmore

(3 reviews) Write a Review
SKU: APN3392519K
Condition: New
Compatible Brands:
Kenmore
Compatible Brands:
Maytag
Compatible Brands:
Whirlpool
$14.25
$3.75
(You save $10.50 )

5% Off Orders Over $75

© 2023 Thrifty Appliance Parts           Some photos taken on 1" x 1" grid.

Replacement thermal fuse used for some Kenmore, Maytag, and Whirlpool dryer models.

Directly Replaces: WP3392519, 3392519, WP3392519VP, 80005, 694511, 3388651, ET401, SET401, G4AP0500, TJ90SET401, 2986, AP6008325, EAP11741460, PD00002311, PS11741460, WE4X857, WE04X0857, 276927, AH268283, AP2042879, EAP268283, PD00030682, PS268283.

Features:

  • Safety fuse that blows in order to cut off power if the dryer overheats.
  • Located on the blower housing.
  • 196°F single blow (non-resettable) limiter.
  • Includes (1) Thermal Fuse.

Specifications:

  • Color: White / Black / Brass.
  • Material: Metal / Plastic.
  • Overall Dimensions: 3/4"L x 9/16"W x 2"H.
  • Additional Dimensions: 3/16" spade terminals.

Compatible Models:

How do I find my model number?
3392519 Dryer Thermal Fuse For Kenmore

Repair Skill Level: 2 | Beginner to Moderate
Minimal disassembly (if any) and some basic tools may be needed.

Part Description: The thermal fulse is a safety fuse that blows in order to cut off power if the dryer overheats.

Failure Symptoms: Dryer won't start; Dryer won't heat.

Testing: Use a multimeter to test it for continuity. If there is no continuity it should be replaced.

Bonus Tip: A blown thermal fuse indicates a restriction in the exhaust vent that runs from the dryer to the outside. Be sure to check the dryer venting whenever you need to replace the thermal fuse. Also check for build up on your lint filter screen. Residue from dryer sheets and fabric softener can build up on lint screens and restrict air flow.

Disclaimer: Information and recommendations contained herein are believed to be accurate as of the date hereof. Since the conditions and methods of use of the information referred to are beyond control, ApplianceRepairForum.com and Thrifty Appliance Parts LLC, cannot be held liable for results obtained or arising from use or reliance on such information.
The User assumes responsibility associated with making test measurements, adjustments, parts replacements and any other action necessary to perform any recommended procedures. It is the responsibility of the User to ask for clarification if a recommendation is not fully understood, including the risks and hazards associated with the recommended procedures.
